Rotary Valve ZKD

Want to find out more about this offering?

The ZKD is an ideal discharging- and metering-valve for handling powders in various industries if transition to rectangular flanges above or below the valve is favored

Download large image

Discharging and metering valve for powders

The ZKD rotary valve is built around a robust, solid housing with rectangular flange connections, giving it the strength and stability needed for demanding industrial applications. This durable design not only extends the valve’s service life but also makes installation and integration into existing systems straightforward. The ZKD also handles fibrous bulk materials with ease, providing reliable feeding performance even in challenging conditions. Equipped with a feeding shoe, it efficiently introduces bulk materials into pneumatic conveying systems at pressures up to 1.5 barg (21 psi). Suitable for industries such as plastics, chemicals, food, and minerals, the ZKD delivers dependable operation tailored to the needs of modern processing environments.

Main features

Pressure range
1.5 barg (21 psi) system and differential pressure
Pressure surge proof
10 barg (145 psi), due to heavy duty design
ATEX (optional)
Usable in Ex-Zones and as protection system (flameproof for dust ST2)
Inlet / outlet
Rectangular design shape of housing corresponds to shape of rotor
Outboard bearings
Separated from product by purged seal arrangement and drop out opening

Related Industries

Plastics
Chemicals
Food & Pet Food
Minerals

ZKD Product Sheet

Access the comprehensive product sheet for the ZKD rotary valve to review its specifications, features, and operational benefits. Gain the technical insights needed to evaluate its suitability for your application.

PRODUCT SHEET

The ZKD features a tangential inlet and reinforced internal surfaces to reduce material impact on the rotor and extend service life.

SUITABLE FOR THE HARSHEST ENVIRONMENTS

The ZKD rotary valve is also built with wear protection in mind, making it a strong performer when handling abrasive bulk materials. Thanks to its design features, even highly abrasive powders or granulates cause significantly less wear over time. As a result, the ZKD maintains consistent performance, reduces unexpected downtime, and delivers extended service life – an important advantage for facilities that run demanding processes or handle tough, erosive products.
